The 810303 Mars torque tube mounting clamp kit shown below allows mounting your Mars unit to the torque tube of a single-axis tracker. Mount your Mars to the mounting bracket with the kit hardware and then use the clamps to secure the bracket to your torque tube.
The torque tube mounting clamp kit can be used on torque tubes or other structural tubing with a circular, square, rectangular, or octagonal profile from 4.5 - 6.0” in width, as shown below.
For more detailed information, please see the Mars User Guide.
